Applications

Access Control

Access Control

Visitor Management

Visitor Management

Business Cards

Business Cards

tickets

Tickets

Print Technology

Inkjet (Single pass printing)

Type of Ink

Dye based ink

Print Color

4 color (BK, C, M, Y)

Dimensions

15.4 (W) x 7.0 (H) x 11.0 (D) inches,

391 (W) x 178 (H) x 280 (D) mm (excluding eject tray)

Weight

Approx. 15.43 lbs. (7kg) Net (without ink tanks)

Print Resolution

1200×1200 dpi

Number of Print Heads

4

Maximum Print Speed

50 sheets / minute

Media size

Business Cards

CR80 Cards (85.6 x 54 mm)

Margin

Top/Bottom – 0.01 inch (0.3mm)

Right/Left – 0.01 inch (0.3mm)

Type of Media

Inkjet coated paper, plastic card

Media Thickness

(Paper Card) 0.08 ~0.15, 0.3 inches (210~370, 760 mm)

(Plastic Card) 0.15 ~0.23, 0.3 inches (394~604, 760 mm)

Applications

PLASTIC CARDS – Temporary pass / employee pass, identification cards (student ID’s)

PAPER CARDS – Business cards, member cards, shopping cards, tags, tickets

Media feeding/ejecting capacity

250 sheets (business card)

100 sheets (plastic card (604 mm thickness)

Interface

USB2.0 high speed, Giga Bit Ethernet

OS

Windows7/8 (32/64 bit), Windows Server 2008, 2012

Ink Cartridge capacity

Approx. 14ml for each color

Manufacturer’s name or trade mark, commercial registration number and address

Kanematsu GMBH,Oststrasse 34, Duesseldorf Germany 40211 TEL-49-211-368-90

Model identifier

PW-150A-1Y240H

Input voltage

230V

Input AC frequency

50Hz

Output voltage

24V

Output current

6.25A

Output power

150W

Average active efficiency

91.8%

Efficiency at low load (10%)

89%

No-load power consumption

0.16W

Brochure
SCC-2000D Brochure .pdf / 474.76 KB
Drivers
SCC-2000D Windows Driver 64bits Ver100 .zip / 10.25 MB
Manuals
SCC-2000D User Guide .pdf / 6.30 MB
SCC-2000D Basic Operation Guide .pdf / 7.76 MB
SCC-2000D Setup Guide .pdf / 12.19 MB
4Y8-8088-020_SCC-2000D_BG .pdf / 7.68 MB
SCC2000D Setup guide .pdf / 8.49 MB
SCC-2000D_UG_EN .pdf / 6.30 MB
SDS
SCC-2000 ink 4444 .zip / 437.17 KB
SCC-D200BK .pdf / 663.21 KB
SCC-D200C .pdf / 227.92 KB
SCC-D200M .pdf / 217.95 KB
SCC-D200Y .pdf / 214.60 KB

SCC Warranty

Applicable to United States / Canada Only

Printer Warranty Coverage

Warranty which SwiftColor passes on to the reseller/customer covers all aspects of the printer except for periodical replacement parts or consumables for the period of 1 year. The warranty covers manufacturing defects, 24-hour web access to online materials, and telephone/email support during SwiftColor hours of operation. General support issues will be acknowledged within 24 hours as long as the request falls within SwiftColor’s hours of operation. The warranty does not cover: (a) The Purge Unit, Blade Cleaner, Transport Unit, Cutter Blade, Maintenance Cartridge and Ink Cartridge unless a factory defect has been determined or if the part has not exceeded its life expectancy; (b) Defects or damage resulting from use of products other than in the normal customary manner; (c) Defects or damage from misused, accident or neglect; (d) Defects or damage from improper testing, operation, maintenance, installation, alteration, modification or adjustment; (e) Product disassembled or repaired in such a manner as to adversely affect performance or prevent adequate inspection and testing to verify any warranty claim; (f) Product which has had the serial number removed or made illegible; (g) Damage caused by the use of incompatible consumables, parts or non-SwiftColor inks.

Print Head Warranty Coverage

The SwiftColor warranty for the print head starts from the date of invoice for a period of 1 year or 200,000 sheets, whichever comes first. An acceptable operation of a print head is 4 non-continuous clogged, missing dots, or misfiring nozzles. The warranty does not cover; (a) Defects or damage resulting from use of products other than in the normal customary manner; (b) Defects or damage from misused, accident or neglect; (c) Defects or damage from improper testing, operation, maintenance, installation, alteration, modification or adjustment; (d) Product disassembled or repaired in such a manner as to adversely affect performance or prevent adequate inspection and testing to verify any warranty claim; (e) Damage caused by the use of incompatible consumables or non-SwiftColor inks.

Ink Cartridge Assurance

The performance assurance period for the ink cartridge is 24 months. The recommended storage environment: S-zone. Procedure Warranty Claims. Customers wishing to claim defective products under warranty terms must contact technical support at 732-271-7328. A technician will diagnose problem/defect and if needed a RO (Return Order) will be issued. Product will be returned for depot service to SwiftColor’s service center or to the closest authorized warranty depot facility for service. Customer is required to pack defective product in a proper manner using original packing box. Printer “shipping mode” procedure has to be properly done by end user before sending such products to repair depot.

Depot Warranty Repair

For Authorized SwiftColor Customers, service turnaround time averages three to five days after the time of receipt of such printer by our authorized repair depot. All labor, replacement parts, and packaging used for warranty repair will be waived except for parts considered as consumables which are mentioned in the Printer Warranty Coverage section under item (a). Shipping charges to SwiftColor’s service center is the customer’s responsibility. SwiftColor will bear the shipping cost to the customer, ground services only. The customer can elect to pay the difference for other shipping services.

THIS WARRANTY IS GIVEN IN LIEU OF ALL OTHER WARRANTIES, EXPRESS OR IMPLIED, WHICH ARE SPECIFICALLY EXCLUDED INCLUDING, WITHOUT LIMITATION, IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE. IN NO EVENT SHALL KG DIGITAL BE LIABLE FOR DAMAGES IN EXCESS OF THE PURCHASE PRICE OF THE PRODUCT, FOR ANY LOSS OF USE, LOSS OF TIME, INCONVENIENCE, COMMERCIAL LOSS, LOST PROFITS OR SAVINGS OR OTHER INCIDENTAL, SPECIAL OR CONSEQUENTIAL DAMAGES CAUSED OUT OF THE USE OR INABILITY TO USE PRODUCTS.
